Model | MT001 | MT002 | MT003 | ||
Rated Power | 2.3kw | 4.05kw | 5. 7kw | ||
Rated Speed | 3600 r/min | 3600 r/min | 3600 r/min | ||
Fuel Type | Gasoline | Diesel | Diesel | ||
Start Mode | Manual start | Recoil type hand start | Pull start | ||
Working Size | 1310X600X950mm | 1620X950 X900mm | 1830X1360X1000mm | ||
Working Speed | 0.1-0.3m/s | 0.1-0.3m/s | 0.1-0.3m/s | ||
Productivity | ≥0.02h㎡ | ≥0.04h㎡ | ≥0.04h㎡ | ||
Fuel Consumption | ≤50kg/hm² | ≤30kg/hm² | ≤30kg/hm² | ||
Working Width | 550mm | 950mm | 1350mm | ||
Transmission Mode | (engine output) Direct connection | ||||
Knife Roll | Gear drive | ||||
Knife Roll (design speed) | 200r/min | 90-120r/min | 50-90r/min | ||
Maximum Turning Radius | 145mm | 180mm | 180mm | ||
Total Number of Installed Knives | 16 | 24 | 38 | ||
Rotary Knife Model | Dry land knife | ||||
Main Clutch Type | Friction plate type | ||||
Status | Normally open | ||||
